Chipset AMD B650
CPU Supports AMD Ryzen™ 9000/ 8000/ 7000
Series Desktop Processors
Socket AM5
Memory 4x DDR5, Maximum Memory Capacity
256GB
Memory
Support DDR5 7200+(OC)/ 7000(OC)/ 6800(OC)/ 6600(OC)/ 6400(OC)/ 6200(OC)/
6000(OC)/ 5800(OC)/ 5600(OC)/ 5400(OC)/ 5200(OC)/ 5000(OC)/ 4800(JEDEC) MHz
Max.
overclocking frequency:
• 1DPC 1R
Max speed up to 7200+ MHz
• 1DPC 2R
Max speed up to 6000+ MHz
• 2DPC 1R
Max speed up to 6000+ MHz
• 2DPC 2R
Max speed up to 5400+ MHz
Supports
Dual-Channel mode
Supports
non-ECC, un-buffered memory
Supports
AMD EXPO
Onboard
Graphics 1x HDMI™
Support
HDMITM 2.1, maximum resolution of 4K 60Hz*
1x
DisplayPort
Supports DP
1.4, maximum resolution of 4K 60Hz*
1x D-Sub
Support
VGA, maximum resolution of 1920x1200 60Hz*
*Available
only on processors featuring integrated graphics. Graphics specifications may
vary depending on the CPU installed.
Slot 1x PCI-E x16 slot (Qty)
• Supports
x16 (For Ryzen™ 9000/ 7000 Series processors)
• Supports
x8 (For Ryzen™ 8700/ 8600/ 8400 Series processors)
• Supports
x4 (For Ryzen™ 8500/ 8300 Series processors)
2x PCI-E x1
slot (Qty)
PCI_E1 Gen
PCIe 4.0 supports up to x16 (From CPU)
PCI_E2 Gen
PCIe 3.0 supports up to x1 (From Chipset)
PCI_E3 Gen
PCIe 3.0 supports up to x1 (From Chipset)
Audio Realtek® ALC897 Codec
7.1-Channel
High Definition Audio
Storage 2x M.2 (Qty)
M.2_1
Source (From CPU) supports up to PCIe 4.0 x4 , supports 2280/2260 devices
M.2_2
Source (From Chipset) supports up to PCIe 4.0 x4 , supports 2280/2260 devices
4x SATA 6G
(Qty)
RAID Supports RAID 0, RAID 1 and RAID 10 for
SATA storage devices
Supports
RAID 0 and RAID 1 for M.2 NVMe storage devices
USB 4x USB 2.0 (Rear)
4x USB 2.0
(Front)
2x USB
5Gbps Type A (Rear)
2x USB
5Gbps Type A (Front)
2x USB
10Gbps Type A (Rear)
1x USB
10Gbps Type C (Front)
LAN Realtek® 8125BG 2.5G LAN
